Cảm biến LE550IC1QP

Cảm biến tiệm quang Turck

Diffuse-Mode Laser Sensor (Triangulation)

With Analog Output

Part number: 3095374Alternative order number : 95374

    • 2-line 8-segment display
    • Cable with male end M12 × 1, 5-pin, PVC, 150 mm
    • Range: 100…1000 mm
    • Laser class 1, red, 650 nm, acc. to IEC 60825-1:2007
    • Resolution at 100 mm – 600 mm distance: < 0.5 mm
    • Resolution at 600 mm – 1000 mm distance: < 1 mm
    • Operating voltage: 12…30 VDC
    • PNP/NPN-switching output, switchable
    • Analog output: 4…20 mA
