Cảm biến LE250KC1QP

Cảm biến tiệm quang Turck

Diffuse-Mode Laser Sensor (Triangulation)

With Switching Output and IO-Link

Part number: 3097768Alternative order number : 97768

    • 2-line, 8-segment display
    • Cable with male end M12 × 1, 5-pin, PVC, 150 mm
    • Range: 100…400 mm
    • Laser class 1, red, 650 nm, acc. to IEC 60825-1:2007
    • Resolution at 100 mm – 250 mm distance: < 0.02 mm
    • Resolution at 250 mm – 400 mm distance: < 0.2 mm
    • Operating voltage: 12…30 VDC
    • 1 × PNP switching output with IO-Link communication
    • Transmission of process value and parametrization via IO-link
