Cảm biến LE250DQP

Cảm biến tiệm quang Turck

Diffuse-Mode Laser Sensor (Triangulation)

With Switching Outputs

Part number: 3094201Alternative order number : 94201

    • 2-line, 8-segment display
    • Cable with male end M12 × 1, 5-pin, PVC, 150 mm
    • Range: 100…400 mm
    • Laser class 2, red, 650 nm, acc. to IEC 60825-1:2007
    • Resolution at 100 mm – 250 mm distance: < 0.02 mm
    • Resolution at 250 mm – 400 mm distance: < 0.2 mm
    • Operating voltage: 12…30 VDC
    • Two switching outputs PNP/NPN configurable
